Pattern 15: Half Milano Plated + Structure with Weft Yarn

Máquina

  • As desired
    • Example for ADF 530-32 W, E 7.2 (classification 688)
  • Técnica de tisaje
    • Todas las agujas
  • Elementos de relleno
    • any yarn color
    • Malla delante con transferencia
  • Comienzo
  • Comienzo, tubular
    • 1 sistema
    • Sin hilo elástico
    • Con hilo de protección
    • Pasada floja

Proyecto de muestra

Pattern-15.spf

Proyecto de corte de líneas

Without shape
  • Plated plating color for the start
  • Color Arrangement for half milano with 1 weft yarn carrier:
    • Plating Color for DJ
    • Additional yarn carrier for Malla atrás (half Milano)
    • Weft yarn defined by plating color (not visible in the design pattern)
      Weft yarn defined by plating color (not visible in the design pattern)
    • Use of the weave-in device
  1. Create a pattern project with one pattern.
  2. Draw basic pattern.
  3. Generate Color Arrangements.
  4. Start the Technical Processing.
  5. Generate knitting program (Sintral, Jacquard, Setup).
  6. Run the Sintral Check.
  7. Load and set up the knitting program on the machine.
