Step 7: Cut

    1
    Cut out the shape with in the Steps of Processing toolbar.
  1. The k&w Options for Cut out dialog box appears.

Cut-out k&w options

    1
    Confirm the settings in the dialog box with OK.
  1. The Insert/Replace k&w Start dialog box appears.

Insert/replace k&w start

    1
    Select the desired k&w start.
    2. 2
    Confirm the settings with OK.
  1. The start module and the information of the k&w Arrangements will be applied to the pattern.

Yarn field dialog box

    1
    Calling-up the Yarn field dialog is possible.
  1. Automatic allocation of the Knot modules in standard situations.
  2. Automatic allocation of the Knitting-in and out modules in standard situations.

To the next step 8: Expanding and completing
