Define Plating Colors and Draw Basic Pattern
I. Define a plating color and draw it into the basic pattern:
- 1
- Open the Plating dialog box with
. - 2
- Create plating color with a Q weft yarn.
- 3
- Make the following settings for the first plating color (P1) in the dialog box:
- at the first position
Yarn color e.g. #1 and the Q for insert of the weft yarn - at the second position
a yarn color e.g. #2 - at the third position
a yarn color e.g. #3
Result:
- 4
- Position the cursor in the line of (P1) of the dialog box and call up the menu with the right mouse button.
- The Plating table with the Plating Offset values (YPI) and the default values will be displayed.
- 5
- Select the desired YPI index from the table.
Yarn color + Q: No YPI necessary as the default for Q (35 nic) is used.
YPI index (1): Leading yarn carrier
YPI index (2): Following yarn carrier - 6
- Position the cursor on the corresponding motif color and click on it with the left mouse button.
- The index will be allocated to the first motif color #2 (leading yarn carrier).
- 7
- Allocate a YPI index to the second motif color at (P1) as well.
- 8
- Enter the settings for the selected YDI index in the table.
- 9
- Fill the basic pattern with yarn color #31 by the plating color (P1).
