Image Import dialog box

Working with the Image Import dialog box

Options to open the dialog box

Importing an image:

    1
    Start the program double-clicking .
    2
    Click 导入图片 in the start page under Start.
    - or -
    In the started CREATE PLUS, in the 文件 ribbon, 导入 tab, select 导入图片.
  1. The Image import dialog box is opened without display of an image.
    2. 3
    Select and open the path of the desired image in the 文件 ribbon over 打开.
    : The following formats can be read: bmp, jpg, jpeg, jpe, jfif, gif, tiff, tif, png
  2. The image reduced by the default settings is displayed in the dialog box under 目标 and the original one under 原始.

Start ribbon

1

导出 group

1x1 方式

The image will be doubled in the width (1x1 technique).

: Attention
Note the knitting technique of the design pattern!

  • 满针
  • 1x1-Technique

This affects the insertion of the image!

到剪贴板

The edited image is copied to the clipboard.

: In the CPS, the image can be inserted in the 花型元素 tool window under Pattern Elements.

创建花型项目

A pattern project with a design pattern is opened from an edited image.

创建设计项目

A design project with a design pattern is opened from an edited image.

2

视图 group

: The settings are displayed only in the 目标，减色数： view.

颜色分割线

Display of the 目标，减色数： view of colored separating lines for subdividing the different areas with different quantity of colors

网格线

Display of a grid in the 目标，减色数： view

颜色列

Display of an additional column in the 目标，减色数： view with the existing colors in each case.

反向选择

Display of the selected color

: Select the color only in the 原始 or in the 目标.

3

图像属性

原始尺寸：

Display of the original size of the image in width x height

目标尺寸：

Edit boxes for the size of the target in width x height

保持纵横比

Size of the image freely changeable in width and height.

Size of the image changeable depending on the aspect ratio.

原始颜色数量

Original quantity of colors in the original image

预减至：

Entry of the quantity of colors to which the image is to be reduced when loading it.

: This, already reduced image will be displayed as 原始.

目标颜色数：

Entry of the quantity of colors for reducing the 原始 to 目标

标准缩减

Type of reduction of an image, e.g. for Jacquard

抖色

Type of reduction of an image with smooth color transitions, e.g. for photos

更新

Apply changes of the settings

4

Display of the 原始 with already previously reduced number of colors

5

Display of the 目标 image with the specified quantity of colors

6

  • Display of all colors in the target
  • For selecting all the original colors of the table that correspond to the target color

: Corresponds to the entry under 目标颜色数： .

7

Table with the following columns

原始

Quantity of colors which were entered at 预减至：.

目标

Allocation of a target color to a original color

: Manual changing of the allocation via the selection menu at the corresponding target color.

属性

 模型外

Allocate 'outside shape' to one or more selected target colors.

: When importing an image, e.g. as shape template

 使用颜色

One or more selected target colors are imported as color in the CPS.

: When importing an image as Jacquard template

 透明

Allocate 透明 to one or more selected target colors.

: When importing an image, which is to be positioned on a specific background.

8

目标

Selection of the target color for the allocation of a property

属性

Selection of the desired property for the selected target color

9

打开方式

Open the original or the target in an image editing app to make changes

10

缩放

Zoom display
